Aggregate Throughput
50 Mbps to 100 Mbps
Total onboard WAN or LAN 10/100/1000 ports
2
RJ-45-based ports
SFP-based ports
1
Enhanced service-module slots
0
Doublewide service-module slots
NIM slots
OIR (all I/O modules)
Yes
Onboard ISC slot
Default memory double-data-rate 3 (DDR3) error-correction-code (ECC) DRAM
(Combined control/services/data planes)
4 GB
Maximum memory DDR3 ECC DRAM (Combined control/services/data planes)
8 GB
Default memory DDR3 ECC DRAM (data plane)
NA
Maximum memory DDR3 ECC DRAM (data plane)
Default memory DDR3 ECC DRAM (control/services plane)
Maximum memory DDR3 ECC DRAM (control/services plane)
Default flash memory
Maximum flash memory
External USB 2.0 slots (type A)
USB console port -type B mini (up to 115.2 kbps)
Serial console port - RJ45 (up to 115.2 kbps)
Serial auxiliary port - RJ45
(up to 115.2 kbps)
Power-supply options
External: AC and PoE
Redundant power supply
N/A
AC input voltage
100 to 240 VAC autoranging
AC input frequency
47 to 63 Hz
AC input current range, AC power supply (maximum)
1.5 to 0.6A
AC input surge current
90 A peak and less than 3 Arms per half cycle
Typical power (no modules) (watts)
36
Maximum power with AC power supply (watts)
125
Maximum power with PoE power supply (platform only) (watts)
260
Maximum endpoint PoE power available from PoE power supply (watts)
120
NA (no PoE support)
